ROUTING MACHINES FOR LOADED BOARD SEPARATION
ADVANCED DUST REMOVAL FOR REAL DUST FREE PRODUCTS
HIGHEST DENT FREE MILLING TECHNOLOGY FOR TIGHT TOLERANCES
SINGLE AND DOUBLE DRAWER
DEDICATED AND UNVERSAL PALLETS

GENERAL FEATURES

HIGH SPEED LINEAR MOTORS ON ALL AXES
MAINTENANCE FREE LINEAR GUIDES
AIR BEARING ROUTING SPINDLES FROM 50K UP TO 180K RPM
SINGLE AND DOUBLE INDEX
WIN OS CNC ABLE TO MANAGE 64 AXES
AUTOMATIC MILLING TOOL CHANGE
HIGH CAPACITY TOOLS LIBRARY
LASER FOR TOOL AND RUNOUT CHECK
AUTOMATIC PANELS HANDLING WITH ROBOTS



TECHNOLOGY HIGHLIGHTS

FLEXIBLE SYSTEM FOR QUALITY PCB DEPANELING APPLICATION
HEAVY-DUTY CAST-IRON BODY
HIGH-END LINEAR MOTOR TECHNOLOGY PROVIDES HIGHLY ACCURATE MOTION PERFORMANCE
INDEPENDENTLY CONTROLLED AXES BY A POWERFUL CNC WHICH INTEGRATES MOTION AND VISION CAPABILITIES
DUST FREE MILLING PROCESS.WITH VACUUM SYSTEM OPTIMIZED WITH PLURITEC’S V-TECS VENTURI TECHNOLOGY BASED ON MORE THAN 50 YEARS OF PCB ROUTING EXPERIENCE
AVAILABLE IN MANUAL, SEMI AUTOMATIC AND FULLY AUTOMATIC CONFIGURATION

EVO DEPANEL - DM

EVO DEPANEL - DR

EVO DEPANEL-DM

product features

Circuits boards depaneling machine
Real dust free and dent free process
Single or double index version
Universal and dedicated pallet solutions
Different spindle models available to choose based on materials RF4 or Aluminium
CCD.camera for perfect alignment to targets
Laser station for tool check and spindle run out
Automatic routing tool change with 14 or 140 positions
QR – QC Code reader

EVO DEPANEL – DR

product features

Fully automated depaneling machine for loaded circuit boards
Automatic panel handling by robot
Real dust free and dent free process
Single or double index version
Universal and dedicated pallet solutions
Different spindle models available to choose based on materials RF4 or Aluminium
CCD.camera for perfect alignment to targets
Laser station for tool check and spindle run out
Automatic routing tool change with 14 or 140 positions
QR – QC Code reader
